Jabsco, flush/bilge pump Maxi Puppy 24V 45 l/min

Description

Jabsco 23610‑3103 is a compact, self-priming wash/bilge pump that delivers high water flow. It is ideal for bilge duties and heavy-duty deck washing, with a capacity of up to 45 liters/minute.

• Brand: Jabsco
• Weight: 3.82 kg
• Amp: 15 A
• Capacity: 45 l/min
• Original no.: 23610-3103
• Fuse size: 15 A
• Hose connection: 25 mm (1") or 1/2" BSP
• Product dimensions: 84 mm × 119 mm × 218 mm
• Package dimensions: Dimensions: 15 cm × 15 cm × 30 cm | Gross weight: 3.82 kg

Jabsco 23610‑3103 is a compact, self-priming wash/bilge pump for onboard use where you need high water flow and reliable operation. It is well suited for both bilge duties and heavy-duty deck washing. The pump can handle up to approx. 45 liters/minute and self-primes up to approx. 2.4 meters lift height. The design is simple and fully serviceable with few wear parts, making maintenance easy. The pump housing can be opened quickly if the impeller needs to be replaced. 23610‑3103 comes with connections for 25 mm (1") hose or 1/2" BSP thread. Mount the pump in a flat, dry, and ventilated location with easy access. Use the supplied rubber grommets to reduce vibration. When mounting vertically, the motor should face upward for correct operation. See the manufacturer's manual for detailed service instructions.
