Ratio, shore power splitter 1:3 16A

Description

This splitter distributes 230 V shore power from one input to three outputs in the Ratio AC16 plug & play system. It makes it possible to distribute shore power to multiple onboard consumers without changing the existing installation.

• Brand: Ratio
• Weight: 0.07 kg
• Amp: 16 A
• Volt: 230 V
• Package dimensions: Gross weight: 0.07 kg

This splitter makes it possible to distribute shore power to multiple onboard consumers without changing the existing installation. It is suitable for boats where the electrical system needs to be expanded in a simple and clear way. The splitter is part of the Ratio AC16 system and functions as a passive distribution unit. It receives one power input and distributes it to three outputs with the same voltage and capacity. The design is developed for stable operation at 230 V. The product is used together with other Ratio AC16 components and fits naturally into modular shore power installations. It can be used both in new systems and for retrofitting where the need for additional connections arises.

The splitter is suitable for both leisure and workboats, where several sockets, chargers or fixed installations need to be powered from the same shore power inlet. The solution provides flexibility and saves space in the installation.
